Design |
Single-cylinder, 4-stroke,
spark-ignition engine, liquid-cooled |
|
Displacement |
349.7 cm³ |
|
Bore |
88 mm |
|
Stroke |
57.5 mm |
|
Starting aid |
Electric starter |
|
Transmission |
6-speed, claw shifted |
|
Engine lubrication |
Forced oil lubrication with 2
Eaton pumps |
|
Primary gear ratio |
24:73 |
|
Secondary gear ratio |
11:48 |
|
Cooling system |
Liquid cooling system,
continuous circulation of cooling liquid with water pump |
|
Clutch |
Wet multi-disc clutch /
hydraulically operated |
|
Ignition system |
Contactless, controlled, fully
electronic ignition system with digital ignition timing
adjustment |
|
Frame |
Perimeter steel-aluminium
composite frame |
|
Fork |
WP Suspension4357
MXMA |
|
Shock absorber |
WP Suspension 4618
PDS DCC |
|
Suspension travel front |
250 mm |
|
Suspension travel rear |
260 mm |
|
Brake system front |
Formula disc brakes |
|
Brake system rear |
Formula disc brakes |
|
Brake discs - diameter front |
240 mm |
|
Brake discs - diameter rear |
210 mm |
|
Chain |
5/8 x 1/4” X‑Ring |
|
Steering head angle |
67° |
|
Wheelbase |
1,418±10 mm |
|
Ground clearance (unloaded) |
325 mm |
|
Seat height (unloaded) |
895 mm |
|
Total fuel tank capacity approx. |
5.5 l
Unleaded premium fuel (95 RON) |
|
Weight without fuel approx. |
99.5 kg |
